ISG Static Mixer

In the search for mixing perfection, some look for complexity. The ISG Static Mixer finds elegance in geometry.

This is not just another static mixer—it is a precisely engineered system where every element has a purpose, every hole has a direction, and every interaction is designed to create order from chaos.

At the core of the ISG design lies a truly unique interface generator—a geometric marvel built around a solid element with four carefully positioned holes. These openings are not merely passages; they are mathematically shaped to form a perfect seal and create a tetrahedral mixing chamber, turning the entire unit into a laboratory of fluid transformation.

Each ISG element operates with purposeful precision:

• Materials enter through four angled holes at the outer perimeter of the inlet side, near the pipe wall.

• They are then guided, divided, and reoriented within the tetrahedral chamber.

• Finally, they exit near the center of the element, transformed and recombined.

This repeated process of peripheral intake and centralized discharge creates a multi-layered convergence of streams—splitting, stretching, and folding them into exponentially increasing interfacial surfaces. The result is a mixing performance that achieves exceptional homogeneity in minimal time and space.

The ISG static mixer is ideal for applications requiring intense yet efficient mixing without moving parts—especially in chemical processing, pharmaceutical production, food and beverage blending, and continuous reaction systems.

No energy input. No maintenance. No compromises. Just intelligent geometry, working in silence.

ISG Static Mixer: Where Flow Becomes Fusion.
